Electronics Engineer Helper

One of the best apps for anyone interested in electronics.
More than 100 thousands users use this app in their work or study.
This app has the following calculators and references:

Datasheet search

Resistor color and digit marking (4, 5 and 6 band color code; 2 symbols, 3/4 digit and EIA-96 code SMD resistors code)

Electronic schematic symbols (IEC 60617, IEEE 315 and GOST standards)

Pinouts Guide (DVI, USB, Display Port, VGA, HDMI, Thunderbolt, Apple, RS-232/422/485, ATX, RCA, MIDI, XLR, Audio Jack, Arduino, Orange Pi, STM32, ESP32, and Raspberry Pi)

Ohms law calculator

AWG converter (wire diameter, cross-section area, resistance and maximum current)

Resistor for LED

Voltage divider

Capacitor code

Capacitor markings

Capacitor ESR tables

Frequency response curve calculation of passive filters (RC, RL, RLC, LC)

Inductor color code

Linear current regulator

SMD packages list

Reactance

PCB trace resistance

Additionally, by purchasing the PRO version of the app, you will get access to additional tools:

SMD components marking codes

Diodes color code (Pro Electron, JEDEC and JIS-C-7012 standards)

Linear voltage regulator

Resistor value to color marking converter

Voltage rectifier

Series or parallel electrical components connection calculator

Diode voltage drop

Minimum PCB trace width

Analog to digital conversion

The PRO subscription is an auto-renewable subscription.
The price of subscription is $1.49 per year, includes 3 months free trial.
Price may vary by location.
The free trial is available only for users who subscribe for the first time.

Payment will be charged to iTunes Account at confirmation of purchase or the end of the Free Trial Period, if any.

Account will be charged for renewal within 24-hours prior to the end of the current period, with the same amount as the first period.

Subscription automatically renews unless auto-renew is turned off at least 24-hours before the end of the current period.

Subscriptions may be managed by the user and auto-renewal may be turned off by going to the users Account Settings after purchase.

Privacy Policy: https: //rengate.github.io/EE-Helper-ToU-and-PP/PP.html

Terms of Use: https: //rengate.github.io/EE-Helper-ToU-and-PP/ToU.html,
